| General Information |
|---|
| Host Name | mx10-14-196-24 |
| IP Address | 192.168.0.61 |
| Time Stamp | 2025-06-24 06:24:00.556 |
| Sequence Number | 327850 [ Info ] |
| Frame Number | 1126585 |
| Image Type | Event |
| Image Path | 10_14_196_24/327/850/E00000.jpg |
| File Size | 55247 bytes (53 KB) |
| System |
|---|
| Model | M15D-Sec |
| Factory IP Adress | 10.14.196.24 |
| Hardware | T3r4.3, 806 MHz |
| Software | MX-V4.1.10.28 |
| Time Server IP(s) | 210.173.160.27 210.173.160.57 210.173.160.87 |
| Current Uptime | 1 day 02:28:08 |
| Event & Action |
|---|
| Event Counter | 1566638 |
| Triggered Events | VM (IMA) |
| Actions | (SO) REC FS |
| Event Status | running |
| Last Event | 2025-06-24 06:23:59 |
| Recording Mode | Continuous Streaming |
| Recording Time | after 10 sec, stop 10 sec |
| Recording Speed | 0.20 fps |
| Event Recording Speed | 1.00 fps |
| Alarm Counter | 239692 |
| Visual Alarm (VA) | hidden |
| Event History |
|---|
| AS (IMA) | 327/849/E00002.jpg [ show info ] |
| VM (IMA) | 856/670/E00003.jpg [ deleted ] |
| PI (ENV) | 235/376/E00005.jpg [ deleted ] |
| UC (SIG) | 321/032/E00000.jpg [ show info ] |
| Sensors |
|---|
| PIR (PI) Level | 1% |
| Video Motion (VM) Window # | 1 |
| Illumination (IL) | n/a | 245.6 lux |
| Signal Input 1 | closed (low) |
| Signal Input 2 | closed (low) |
| Buttons (BT) | none |
| Camera Temperature | 14.7°C (58.4°F) |
| Ambient Temperature | 21.9°C (71.4°F) |
| Image Setup |
|---|
| Image Codec | MxPEG (32768 KBytes) |
| Image Properties | Right, R=Full Image, L=Full Image, 640x480, 60% JPEG quality, Live |
| Mounting | Wall | Wall |
| Digital Zoom | 1.0x | 1.0x |
| Sharpness | 4 | 4 |
| Noise Suppress | low | low |
| Auto Contrast | off | auto |
| Brightness | 0 | 0 |
| Backlight | 4 | 4 |
| Night Improve | off | on (19.9%) |
| Exposure Field | all | all |
| Exposure Field Weighting | 0% | 100% |
| White Balance Weighting | 0% | total |
| Average Brightness | 0.0% | 39.8% |
| White Balance Range | 0% | 100% |
| Hardware Default (G1 R B G2) | 0 0 0 0 | 1024 1024 1024 1024 |
| Color Saturation | b/w | 0 |
| Blue Balance | 0 | 0 |
| Red Balance | 0 | 0 |
| Current Auto Contrast | 0→0 | 0→0, 11→0, 231→255, 255→255 |
| Used Auto Contrast | 0→0 | 10→0, 232→255, 255→255 |
| Current Color (G1 R B G2) | 0.0 0.0 0.0 0.0 | 103.2 105.3 97.4 104.0 |
| White Balance Color (G1 R B G2) | 0.0 0.0 0.0 0.0 | 118.3 120.4 116.3 119.3 |
| Current Correction (G1 R B G2) | 0 0 0 0 | 1099 1080 1118 1089 |
| Black Level (G1 R B G2) | 0.0 0.0 0.0 0.0 | 11.6 11.4 11.4 11.6 |
| Used Color Correction (G1 R B G2) | 0 0 0 0 | 1100 1080 1116 1090 |
| Hardware Gain (G1 R B G2) | 0 0 0 0 | 2560 3584 3072 2560 |
| Exposure Time | 0.00 ms (prog=+0, min=0.00 ms, max=0.00 ms) | 10.0 ms (prog=+0, min=0.16 ms, max=160 ms) |
| Exposure Control Flags | not set | exposure frozen
hold |
| Reference Illumination | | 1584.5 lux (64.0 dB) |
| Control Duration | | 0 images |
| Stable Counter | | 126 images |
| Gain Change (G1 R B G2) | 0.00 0.00 0.00 0.00 | 0.00 0.00 0.00 0.00 |
| Frame Rate | 1 fps |
| Power Supply Frequency | 50 Hz |
